Description
Cisco Catalyst 2960 Series Intelligent Ethernet Switches are a new family of fixed-configuration standalone devices that provide desktop Fast Ethernet and Gigabit Ethernet connectivity, enabling enhanced LAN services for entry-level enterprise, mid-market, and branch office networks. The Catalyst 2960 Series offers integrated security, including network admission control (NAC), advanced quality of service (QoS), and resiliency to deliver intelligent services for the network edge.
Manufactured by: CISCO
Model/Part #: WS-C2960-24TT-L
General
Device Type Switch
Enclosure Type Rack-mountable – 1U
RAM 64 MB
Flash Memory 32 MB flash
Ports Qty 24 x Ethernet 10Base-T, Ethernet 100Base-TX
Auxiliary Network Ports 2×10/100/1000Base-T(uplink)
Data Transfer Rate 100 Mbps
Data Link Protocol Ethernet, Fast Ethernet
Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, SSH-2
Communication Mode Half-duplex, full-duplex
Switching Protocol Ethernet
MAC Address Table Size 8K entries
Status Indicators Link activity, port transmission speed, port duplex mode, power, link OK, system
Layer 2 switching, auto-sensing per device, auto-negotiation, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, E-mail alert, DHCP snooping, Port Aggregation Protocol (PAgP) support, Trivial
File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP)
Expansion / Connectivity
Interfaces 24 x network node – Ethernet 10Base-T/100Base-TX – RJ-45 female 2 x network host – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45 female
Authentication Method RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Compliant Standards CE, FCC Class A certified, TUV GS, cUL, NOM, VCCI Class A ITE, IEC 60950, EN55024, EN55022 Class A, CSA 22.2 No. 60950, FCC Part 15, MIC, UL 1950 Third Edition, UL 60950-1, EN 60950-1
Power Device Power supply – internal
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational 28 Watt
Redundant Power System (RPS) connector
Software / System Requirements
Min Operating Temperature 23 ?F
Max Operating Temperature 113 ?F
