Description
Cisco Catalyst 2960 Intelligent Ethernet Switches enable entry-level enterprise, medium-sized, and branch office networks to provide enhanced LAN services. This family of fixed-configuration, standalone devices provide desktop 10/100 Fast Ethernet and 10/100/1000 Gigabit Ethernet connectivity.
Manufactured by: CISCO
Model/Part #: WS-C2960-24TC-S
Device Type Switch
Enclosure Type Rack-mountable – 1U
RAM 64 MB
Flash Memory 32 MB flash
Ports Qty 24 x Ethernet 10Base-T, Ethernet 100Base-TX
Auxiliary Network Ports 2×10/100/1000Base-T/SFP (mini-GBIC)(uplink)
Data Transfer Rate 100 Mbps
Data Link Protocol Ethernet, Fast Ethernet
Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9,
Telnet, SNMP 3, SNMP 2c, HTTP
Connectivity Technology Wired
Communication Mode Half-duplex, full-duplex
Switching Protocol Ethernet
MAC Address Table Size 8K entries
Status Indicators Link activity, port transmission speed, port duplex mode, power, link OK, system
Features Layer 4 switching, layer 2 switching, auto-sensing per device,
DHCP support, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Quality of Service (QoS)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah
Expansion Slots Total (Free) 2 ( 2 ) x SFP (mini-GBIC)
Interfaces 2 x network host – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45 24 x network node – Ethernet 10Base-T/100Base-TX – RJ-45
Power Device Power supply – internal
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational 30 Watt
Features Redundant Power System (RPS) connector
Min Operating Temperature 32 ?F
Max Operating Temperature 113 ?F
Humidity Range Operating 10 – 85%
Width 17.5 in
Depth 9.3 in
